Dimensionality Reduction in Machine Learning

Dimensionality Reduction

Dimensionality reduction is a type of unsupervised learning.

The idea is simple:

Take high-dimensional data and represent it using fewer dimensions while preserving as much important structure as possible.

• This is an approximation.
• We lose some information because we are projecting.
• But if most of the data lies near a lower-dimensional structure, the loss is small.

Usually we start with:

$$x^{(i)} \in \mathbb{R}^n$$

And reduce to:

$$z^{(i)} \in \mathbb{R}^k \quad \text{where } k < n$$

Example:

• 1000D → 100D
• 300D → 50D

Dimensionality reduction finds:

• A lower-dimensional subspace (line, plane, etc.)
• That captures most of the variance in the data

Then it projects the data onto that subspace.

Advantages

There are two main reasons:

1. Data Compression

• Store fewer numbers per example
• Reduce memory and disk usage

2. Faster Learning

• Many algorithms scale with number of features
• Fewer features → faster training and prediction

What Projection Means

Suppose original examples are:

$$x^{(i)} \in \mathbb{R}^2$$

After projection onto a line:

$$z^{(i)} \in \mathbb{R}$$

So instead of storing:

$$x^{(i)} = \begin{bmatrix} x_1^{(i)} \\ x_2^{(i)} \end{bmatrix}$$

We store:

$$z^{(i)}$$

One number instead of two.

---

Example 1: Redundant Features (2D → 1D)

Suppose:

• $x_1$ = length in centimeters
• $x_2$ = length in inches

These features are highly correlated.

Instead of storing:

$$x = \begin{bmatrix} x_1 \\ x_2 \end{bmatrix}$$

We can project the data onto a line and represent each example with a single number:

$$z_1$$

So:

• Original representation: 2 numbers per example
• Reduced representation: 1 number per example

We approximate the original data by projecting onto a line that captures the main direction of variation.

---

Example 2: 3D → 2D

Now suppose:

$$x^{(i)} \in \mathbb{R}^3$$

But the data roughly lies on a plane.

Instead of keeping 3 coordinates:

$$x^{(i)} = \begin{bmatrix} x_1^{(i)} \\ x_2^{(i)} \\ x_3^{(i)} \end{bmatrix}$$

We project onto a 2D plane and represent each example as:

$$z^{(i)} = \begin{bmatrix} z_1^{(i)} \\ z_2^{(i)} \end{bmatrix} \in \mathbb{R}^2$$

Now we only need two numbers instead of three.

---

Summary

Dimensionality reduction:

• Removes redundancy
• Compresses data
• Speeds up learning
• Represents high-dimensional data using fewer variables

In the next step, we usually use Principal Component Analysis (PCA) to compute the optimal projection direction mathematically.

Example: Countries Dataset

Suppose we collect a large dataset containing statistics about countries around the world.

Each country may have 50 features, such as:

• $x_1$ = GDP (Gross Domestic Product)
• $x_2$ = GDP per capita
• $x_3$ = Human Development Index
• $x_4$ = Life expectancy
• $x_5, x_6, \dots$

Each country is represented as:

$$x^{(i)} \in \mathbb{R}^{50}$$

So every country corresponds to a 50-dimensional feature vector.

Reducing 50D to 2D

Using dimensionality reduction, we can transform each country:

$$x^{(i)} \in \mathbb{R}^{50} \quad \longrightarrow \quad z^{(i)} \in \mathbb{R}^{2}$$

Now each country is represented by only two numbers:

$$z^{(i)} = \begin{bmatrix} z_1^{(i)} \\ z_2^{(i)} \end{bmatrix}$$

This allows us to plot every country as a point in 2D space.
