MatLab (MATrix LABoratory)

MATLAB is a high-level language and interactive environment built for numerical computing, matrix operations, data analysis, visualization, and algorithm development.

It is widely used in engineering, research, AI/ML, signal processing, control systems, and finance.

Learning Path

• MATLAB On Ramp
• Deep Learning On Ramp
• Machine Learning on Ramp
• Reinforced Learning on Ramp
• Fundamentals of Programming

---

Install and Run

Follow instructions

brew install octave

octave --gui

Finding Help

doc fn — documentation for a function

% — add a comment

• pwd — get current directory
• cd — change directory
• ls — list directory
• who — view variables in current scope
• whos — detailed view of variables in scope
• clear — clear variables in current workspace

---

Data Types

Numeric Types

Integer and floating-point data:

• unsigned Int: uint8/16/32/64
• signed Int: int8/16/32/64
• single — 4 byte float
• double — 8 byte double precision

Characters and Strings

Text in character arrays and string arrays

Dates and Time

Arrays of date and time values that can be displayed in different formats

Categorical Arrays

Arrays of qualitative data with values from a finite set of discrete, nonnumeric data

Tables

Arrays in tabular form whose named columns can have different types

Structures

Arrays with named fields that can contain data of varying types and sizes

Cell Arrays

Arrays that can contain data of varying types and sizes

Function Handles

Variables that allow you to invoke a function indirectly

---

Variables

Precision

format long   % up to 10+ decimal places
format short  % up to 4 decimal places

Rules:

• Starts with alphabets
• Can contain a-z, A-Z, 0-9, and _
• Can see data value by entering variable name

Saving & Loading

save <filename>.mat               % save all variables
save <filename>.mat <varName>     % save single variable
save <filename>.txt -ascii        % save in readable format

load <filename>.mat               % load all variables
load <filename>.mat <varName>     % load single variable

clear                             % empty workspace

---

Creating Arrays & Matrices

magic(n,m)   % sum of rows, columns, and diagonal is same

x = [7 9]         % row array / row vector
x = x'            % transpose into column vector

x = start:end              % row vector [1,2,3,4]
x = start:step:end         % row vector 1 to 5 step 0.5
x = (start:step:end)'      % column vector

x = linspace(start, end, n)    % equidistant row vector with n points
x = linspace(start, end, n)'   % equidistant column vector with n points

• , separates elements in the same row
• ; separates rows

x = [7,9]        % row array [element , element]
x = [7;9]        % column array [element ; element]
x = [4,5 ; 7,9]  % 2D matrix [ROW; ROW]

x = rand(n)      % nxn matrix with random numbers
x = rand(n,m)    % nxm matrix with random numbers

x = zeros(n,m)   % nxm matrix of zeros
x = ones(n,m)    % nxm matrix of ones

x = eye(n,m)     % nxm matrix with 1s on the diagonal
x = eye(n)       % nxn identity matrix

Trick: A.*eye(n) = diagonal matrix of A

---

Reading Values from a Matrix

Indexing starts at 1.

length(V)              % length of vector
size(A)                % size of matrix
[dr, dc] = size(A)     % size into dr, dc
[vMax, ivMax] = max(A) % max value and its index

A(:)                   % convert matrix into single column vector

A(i)                   % ith element of vector
A(n:m)                 % elements from index n to m

A(i,j)                 % ith row, jth column
A(end,j)               % last row, j column
A(n, :)                % all elements of nth row
A(:, n)                % all elements of nth column
A(:, end-1:end)        % all elements of last 2 columns
A([a,b], :)            % all elements of rows a and b

Tricks

[vMax, ivMax] = max(A)  % max value and its index
max(A,[],1)             % max per column
max(A,[],2)             % max per row
max(A(:))               % max element in A

sum(A,1)                % per column sum
sum(A,2)                % per row sum

sum(sum(A.*eye(n)))     % sum of all diagonal elements of A

---

Update Values in a Matrix

A(i) = b        % modify ith element to b
A(i,j) = b      % modify (i,j) element to b

C = [A,B]       % concatenate B after last column of A
C = [A;B]       % concatenate B below last row of A
A = [A,[a;b;c]] % append column to A

Operations on a matrix apply to all elements:

A + b        % add scalar b to all elements
A / b        % divide all elements by scalar b

A < 3                   % element-wise compare, returns binary matrix
[r,c] = find(A<3)       % row and column indices satisfying condition

A + B        % matrix addition
A.*B         % element-wise multiplication

Built-in Functions

fn(A)     % apply math fn to all elements (sqrt, abs, log, etc.)
sum(A)    % sum of all elements
prod(A)   % product of all elements
floor(A)  % floor (0.5 → 0)
ceil(A)   % ceiling (0.5 → 1)

Inverse

pinv(A)      % pseudo-inverse of matrix
pinv(A)*A    % identity matrix of A

---

Operators

Arithmetic Operators

+, -, *, /, ^, ()

Order of operations: () > ^ > *, / > +, -

A^n

Matrix power — repeated matrix multiplication ($A \times A \times \dots \times A$, n times). Only valid when A is square.

A.^n

Element-wise power — raises each element individually to the nth power. Works for any shape.

A.*B

Element-wise multiplication — multiplies corresponding elements.

Matrix Multiplication (A*B)

Given $A(m \times n)$ and $B(n \times o)$, result is $C(m \times o)$ where $C(i,j) = \sum_k A(i,k) \times B(k,j)$.

Dot Product / Inner Product

RowVector(1×n) * ColumnVector(n×1) = Scalar

Outer Product

ColumnVector(n×1) * RowVector(1×n) = Matrix(n×n)

Right Divide (./)

A./B  % divide each element of A by corresponding element of B
A./b  % divide all elements of A by scalar b

Left Divide (.)

A.\B  % divide each element of B by corresponding element of A

---

Relational Operators

<, >, <=, >=, ==, ~=

A > B   % returns 1/0 array comparing each element of A with B
A > b   % returns 1/0 array comparing each element with scalar b

Notes:

• >, <, >=, <= — compare only the real part for complex numbers
• ==, ~= — test both real and imaginary parts
• Inf == Inf is true; NaN ~= NaN is true

---

Logical Operators

• Assert: true, false
• Logic: |, &, ~, xor
• Short circuit: ||, &&

x = v1(v1<4 & v1>2)   % all values of v1 between 2 and 4

L = logical(A)          % converts A to logical array (0→false, nonzero→true)

---

Control Flow

If Else

if (condition)
    ...body
elseif (condition)
    ...body
else
    ...body
end

While

while (condition)
    ...body
    continue   % skip this step
    break      % exit loop
end

For Loop

for v = start:step:end
    ...body
    continue   % skip this step
    break      % exit loop
end

Switch Case

MATLAB executes only one case. Variables defined within a case are not available in other cases.

• case_expression must be a scalar, character vector, or cell array of scalars/character vectors
• switch_expression must be a scalar or character vector

switch switch_expression
    case case_expression
        ...body

    case {case_expression1, case_expression2}   % fall-through group
        ...body

    otherwise
        warning('Unexpected value.')
end

Try Catch

try
    ...body

catch ME
    switch ME.identifier
        case 'MATLAB:UndefinedFunction'
            warning('Function is undefined. Assigning NaN.');

        case 'MATLAB:scriptNotAFunction'
            warning('Attempting to execute script as function.');

        otherwise
            rethrow(ME)
    end
end

MATLAB allows nested try/catch but does not support multiple catch blocks or a finally block.

---

Functions

Single Output

function out = fnName(param1, param2)
    ...body
end

Multiple Outputs

function [out1, out2] = fnName(param1, param2)
    ...body
end

Example:

function y = squareThisNumber(x)
    y = x^2;
end

function [y1, y2] = squareAndCubeThisNumber(x)
    y1 = x^2;
    y2 = x^3;
end

Anonymous Function

Returns a single output. Can be passed as input to other functions. f is called a Function Handle.

f = @(params) expression

---

Object-Oriented Programming

Classes

A MATLAB class lives in its own file named after the class, starting with classdef.

% File: Point.m
classdef Point
    properties
        x
        y
    end

    methods
        function obj = Point(x, y)   % constructor
            obj.x = x;
            obj.y = y;
        end

        function d = distanceFromOrigin(obj)
            d = sqrt(obj.x^2 + obj.y^2);
        end
    end
end

Usage:

p = Point(3, 4);
p.distanceFromOrigin()   % 5

Properties

Hold the state/data of an object — equivalent to fields in other OOP languages.

properties
    x
    y = 0          % default value
end

properties (Access = private)
    secret         % only accessible inside the class
end

Methods

Functions that operate on an object's properties. The first argument is conventionally obj.

methods
    function obj = setX(obj, newX)
        obj.x = newX;   % MATLAB objects are value types — must return obj
    end
end

Constructor

A method with the same name as the class, called automatically on instantiation. If omitted, MATLAB provides a default no-argument constructor.

Inheritance

A subclass extends a base class using < BaseClassName.

classdef Point3D < Point
    properties
        z
    end

    methods
        function obj = Point3D(x, y, z)
            obj = obj@Point(x, y);   % call superclass constructor
            obj.z = z;
        end

        function d = distanceFromOrigin(obj)
            d = sqrt(obj.x^2 + obj.y^2 + obj.z^2);   % overrides parent method
        end
    end
end

Encapsulation

Restrict access to internal state using Access attributes.

properties (Access = private)
    balance = 0
end

methods
    function obj = deposit(obj, amount)
        obj.balance = obj.balance + amount;
    end

    function b = getBalance(obj)
        b = obj.balance;
    end
end
