Terraform Modules: How to Use & Create

Terraform modules - 11%

Objective

• Contrast and use different module source options including the public Terraform Module Registry
• Interact with module inputs and outputs
• Describe variable scope within modules/child modules
• Set module version

Modules

Small, reusable Terraform configurations that let you manage a group of related resources as if they were a single resource.

A collection of resources that make up a specific piece of infrastructure

• ✅ Initialize & download (providers + modules) using: terraform init
• ✅ Refresh/download just the modules (without a full re-init) using: terraform get

        ├── LICENSE
        ├── README.md
        ├── main.tf
        ├── variables.tf
        ├── outputs.tf

Modules Usage

• Organize configuration
• Encapsulate configuration
• Re-use configuration

Loading Modules

Terraform cache these modules in the .terraform/modules subdirectory in the current working directory

Modules can either be loaded from the local filesystem directory

  module "website_s3_bucket" {
   source = "./modules/aws-s3-static-website-bucket"
  }

or a remote source such as

• Terraform Registry
• version control systems,
• HTTP URLs
• Terraform Cloud
• Terraform Enterprise private module registries.

Verified Module

Reviewed by Hashicorp & maintined by contributors

• Verified badge is shown for official modules
• Unverified module does not mean low quality and vice versa

Note: Only the official or verified modules are visible in Terraform Registry search results

Child Module

A module that is called by another configuration is referred to as a child module of that configuration.

  module "servers" {
      source = "./app-cluster" # Child Module
  }

Output

module.<MODULE NAME>.<OUTPUT NAME>

Access IP address of

module.web_server.instance_ip_addr.

Supported Arguments

• The source argument is mandatory for all modules.
• The version argument is recommended for modules from a registry.
• Meta-arguments
  • count - Creates multiple instances of a module from a single module block.
  • for_each - Creates multiple instances of a module from a single module block.
  • providers - Passes provider configurations to a child module.
  • depends_on - Creates explicit dependencies between the entire module and the listed targets.

Public Module

downloadeble from Terrform registry

• Accesses by <Namespace>/<Name>/<Provider>

Publishing a Public module

• ✅ The module must be on GitHub and must be a public repo. Not needed for private module
• ✅ x.y.z tags for releases: at least one release tag must be present e.g. v1.0.4 and 0.9.2
• ✅ Module repositories must use this three-part name format, terraform-<PROVIDER>-<NAME> e.g. terraform-aws-vpc
• Follow standard module structure.

Private Module

Downloadable from Terrform Cloud after terrform login or using API token in CLI

• Accesses by <HostName>/<Namespace>/<Name>/<Provider>

Module Sources

Local paths

  #local module
  module "servers" {
    source = "./app-cluster"
  }

From Terraform Registry

  # Public module
  # <Namespace>/<Name>/<Provider>
  module "consul" {
    source  = "hashicorp/consul/aws"
    version = "0.0.5"
  }

  # Private Module

  # <HostName>/<Namespace>/<Name>/<Provider>
  module "consul" {
    source  = "app.terraform.io/example-corp/k8s-cluster/azurerm"
    version = "1.1.0"
  }

Github

  # HTTP
  module "consul" {
    source = "github.com/hashicorp/example"
  }

  # SSH
  module "consul" {
    source = "git@github.com:hashicorp/example.git"
  }

  # select a specific tag
  module "vpc" {
    source = "git::https://example.com/vpc.git?ref=v1.2.0"
  }

  #  Generic Git repo with HTTP
  module "vpc" {
    source = "git::https://example.com/vpc.git"
  }

  #  Generic Git repo with SSH
  module "storage" {
    source = "git::ssh://username@example.com/storage.git"
  }

  # directly select a commit using its SHA-1 hash
  module "storage" {
    source = "git::https://example.com/storage.git?ref=51d462976d84fdea54b47d80dcabbf680badcdb8"
  }

BitBucket

  module "consul" {
   source = "bitbucket.org/hashicorp/terraform-consul-aws"
  }

HTTP

  module "vpc" {
    source = "https://example.com/vpc-module?archive=zip"
  }

Supported Zipped format

• zip
• tar.bz2 and tbz2
• tar.gz and tgz
• tar.xz and txz

S3 Bucket

  module "consul" {
    source = "s3::https://s3-eu-west-1.amazonaws.com/examplecorp-terraform-modules/vpc.zip"
  }

GCP bucket

  module "consul" {
    source = "gcs::https://www.googleapis.com/storage/v1/modules/foomodule.zip"
  }
