Deploying Agents at Scale

NVIDIA Inference Stack ⚡

flowchart TD

    Training["Training <br/> PyTorch / NeMo Model"]--> Model["ONNX 📦"]

    User --> NIM["NIM <br/> Production APIs"]

    NIM --> Triton["Triton Server 🐳 <br/>Inference"]


    Triton--> TensorRT-LLM["TensorRT-LLM 🖲 <br/> Runtime"]

    Model-->TensorRT-LLM

    TensorRT-LLM--> GPU["GPU Rack 🧮"]

Components

Component	Purpose
CUDA	GPU execution platform
TensorRT-LLM	LLM optimization
Triton	Model serving
NIM	Packaged inference microservice
Kubernetes	Deployment & scaling

Build using Docker 🐳

Packages the agent, its model config, tool dependencies, and runtime into a single reproducible image.

Pin all versions model weights, libraries, Python for deterministic builds.

Pipeline

flowchart TD

    Commit["code commit 📤"]
    Eval["Automated Eval 🔎"]
    Build["Container Build 📦"]
    Deploy["Shadow Deployment 🚛 "]
    rollback["Promote/Rollback 🐳"]

    Commit-->Eval-->Build-->Deploy-->rollback

Automated Eval 🔎

Running a benchmark suite against a golden dataset to catch regression in agent behaviour before it reaches users.

Shadow Deployment 🚛

Benchmarking new build with real user traffic against existing prod deployment without affecting any user

Goal

• Observe performance with real world traffic
• Validate if model is performing well
• Benchmark with current Live Model

More of this in next Post

Validate with real traffic.

flowchart LR

    User
    --> Production

    User -. Mirror .-> Shadow

    Production --> Response

    Shadow -. Discard .-> Trash

Promote/Rollback 🐳

Final Rollout to production using BlueGreen or Canary Deployment

Expose to a real users gradually with Canary.

---

Kubernetes ☸️

Orchestrates multiple containers at scale.

Handles scheduling, health checks, rolling updates, and auto-scaling.

Each agent type runs as a Deployment with its own replica count and resource limits.

production-grade pattern used by many AI agent platforms.

1. Deploy stateless agent workers as a Kubernetes Deployment.
2. Use Redis or Kafka as a task queue.
3. Expose queue depth as an external metric.
4. Configure an HPA or KEDA ScaledObject.
5. Scale replicas based on queue depth.
6. Store session state and memory externally.

flowchart LR

    Producers --> Queue

    Queue --> Agent1
    Queue --> Agent2
    Queue --> Agent3

    Queue -. task_queue_depth .-> HPA

    HPA -. Scale Up/Down .-> Deployment

    Deployment --> Agent1
    Deployment --> Agent2
    Deployment --> Agent3

Horizontal Pod Autoscaler (HPA) ↔️

Scales replica count up/down based on CPU, memory, or custom metrics (e.g. queue depth).

Handles traffic spikes without manual intervention.

Example application/deployment.yaml

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler # Horizontally scale pods
metadata:
  name: agent-worker-hpa  # identifier for deployment
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: agent-worker
  minReplicas: 2 # HPA will never scale below 2 replicas
  maxReplicas: 20 # Never scale above 20 pods
  metrics:
  - type: External
    external:
      metric:
        name: task_queue_depth   # custom metric from Redis
      target:
        type: AverageValue
        averageValue: "10"       # scale when >10 tasks/replica

Deploying agent-worker-hpa

Deployment

kubectl apply -f https://k8s.io/examples/application/deployment.yaml

Validate

# Verify deployment
kubectl get deployment agent-worker

# Verify HPA
kubectl get hpa

# Debug HPA
kubectl describe hpa agent-worker-hpa

---

Hierarchical orchestration

One orchestrator agent fans out sub-tasks to specialist workers.

The orchestrator holds the plan; workers are stateless executors.

At scale, the orchestrator itself can be replicated with task queues (Redis, Kafka) providing coordination.

Horizontal agent scaling

Deploy multiple identical worker agent replicas behind a load balancer.

Each replica handles independent tasks

Stateless design is key so any replica can pick up any task.

flowchart TD

    Producers["Producers / API Gateway 🔀 "]
    LoadBalancer["Load Balancer 🚦 "]

    AgentA["Agent Replica A 🤖 <br/>Stateless"]
    AgentB["Agent Replica B🤖 <br/>Stateless"]
    AgentC["Agent Replica C 🤖<br/>Stateless"]

    Queue["Task Queue 📥 <br/>Redis / Kafka"]

    Session["Session State ℹ️ <br/>Redis / DynamoDB"]
    LTM["Long-Term Memory 🛢 <br/>Vector DB / RAG"]
    ToolCache[Tool Cache<br/>Redis / Memcached]

    Producers --> LoadBalancer

    LoadBalancer --> |monitor| AgentA
    LoadBalancer --> |monitor| AgentB
    LoadBalancer --> |monitor| AgentC

    Producers --> Queue

    Queue --> |poll| AgentA
    Queue --> |poll| AgentB
    Queue --> |poll| AgentC

    AgentA <--> Session
    AgentB <--> Session
    AgentC <--> Session

    AgentA <--> LTM
    AgentB <--> LTM
    AgentC <--> LTM

    AgentA <--> ToolCache
    AgentB <--> ToolCache
    AgentC <--> ToolCache

KEDA (Kubernetes Event-Driven Autoscaling)

Extends Kubernetes autoscaling beyond CPU and memory.

Common triggers:

• Redis Queue Depth
• Kafka Lag
• RabbitMQ Queue Length
• AWS SQS Messages

KEDA automatically creates and manages an HPA.

flowchart LR

    Queue -. Queue Depth .-> KEDA

    KEDA --> HPA

    HPA --> Deployment

Task queue decoupling 📥

Decouple task submission from execution via a queue.

Producers push tasks; agent workers pull and process.

Enables backpressure, retry, and independent scaling of producers vs consumers.

1. Routes by queue depth

Reads the actual task queue depth from each replica (or from Redis) and routes to the one with the shortest queue.

The most accurate signal for agent workloads — accounts for queued but not-yet-started tasks.

2. Round Robin

Cycles through replicas in order regardless of their current load.

Simple and fair for uniform workloads, but can create hotspots when some agent tasks take much longer than others.

3. Least Connection

Always picks the replica with the fewest active tasks.

Ideal for agents because task duration varies wildly

a 20-step reasoning chain holds a connection far longer than a 2-step lookup.

4. Weighted

Replicas are assigned weights reflecting their capacity.

• A GPU-backed replica might get weight 3, a CPU replica weight 1 — meaning it receives 3× the traffic.

Good when replicas have different specs.

5. Random

Picks a replica at random.

Statistically converges to even distribution at scale but can cluster by chance on small request counts.

Low overhead — no state to track.

ConfigMap / Secret 🔑

Externalise model endpoint URLs, API keys, and policy configs from the image enables config changes without a rebuild.

GPU node pool

Schedule inference pods on GPU nodes using nodeSelector or taints/tolerations. NVIDIA device plugin exposes GPUs as schedulable resources.

---
