Retrieval-Augmented Generation (RAG) 🧼

Large Language Models are powerful, but they have one major limitation: they don't know your private data.

If you ask a model about your company docs, support tickets, or internal knowledge base, it will hallucinate or say it doesn't know.

Retrieval Augmented Generation (RAG) solves this.

Instead of relying only on the model's training data, we retrieve relevant documents at query time and inject them into the prompt.

In this post we’ll walk through how to build a production RAG system step-by-step, including architecture, scaling concerns, and engineering tradeoffs.

What is RAG?

Helps LLM generate answers grounded in retrieved knowledge based on Vector DB of existing knowledge.

RAG combines two components:

1. Retriever
2. Generator (LLM)

Core idea:

$$LLM + Retrieval = Useful AI System$$

Without RAG we ask LLM directly:

User → LLM → Answer

With RAG we add a context retrieval step to improve the answer:

$$Query \rightarrow Embedding \rightarrow Vector Search \rightarrow Context Retrieval \rightarrow LLM Generation$$

RAG is becoming the default architecture for AI products. But building it reliably in production requires careful engineering.

Advantages of RAG

• Access private knowledge: This allows models to answer questions about private or up-to-date data.
• Reduce hallucinations: By grounding the model in retrieved documents, it reduces the chance of generating false information.
• Stay up-to-date: Give the model access to external knowledge.

How RAG Works

RAG works in three steps:

1. Search relevant documents for an answer
2. Insert retrieved text into the prompt
3. Generate the answer from the updated prompt.

Given:

$$q = \text{user query}$$

$D$ represents the document set.

$$D = \{d_1, d_2, ..., d_n\}$$

The RAG system retrieves the most relevant document

$$d^* = \arg\max_{d_i \in D} \; \text{similarity}(q, d_i)$$

Then the LLM generates a response conditioned on (q) and (d^*).

flowchart TD
    Q[User question ❓] --> R1[Retrieve relevant documents 📁]
    R1 --> R2[Insert retrieved context into prompt ℹ️]
    R2 --> LLM[LLM generates answer 📄]
    LLM --> A[Grounded response 💬]

Conceptually, the prompt becomes:

$$\text{Prompt} = \text{Instruction} + \text{Retrieved Context} + \text{Question}$$

For example:

$$\text{Answer} = \text{LLM}(\text{Instruction} + \text{Parking Policy} + \text{Question})$$

This is powerful because the LLM is being used more as a reasoning engine than as a pure source of facts.

It reads relevant text and uses that text to formulate an answer

Building a Production RAG System

Step 1 — Data Collection 📂

Your RAG system is only as good as the documents you feed it.

We need to collect and index all relevant documents that the model can retrieve from.

Rag will search through this documents vector DB to find relevant context for the user query.

Typical sources:

• Confluence Pages
• Slack threads
• GitHub repos
• Product docs & Wiki
• Policy Docs eg. PDFs

Example pipeline:

flowchart TD
    A["Data Sources 📚"] --> B["Document Loader 📕"]
    B --> C[Text Cleaning 📖]
    C --> D[Chunking 📑]

Python example:

from langchain.document_loaders import PyPDFLoader

loader = PyPDFLoader("docs/architecture.pdf")
documents = loader.load()

Step 2 — Chunking Documents 📑

Instead of embedding an entire document, we split it into chunks.

LLMs have context limits (e.g. 4k tokens), so we need to break documents into smaller pieces.

Chunk Size	Tradeoff
Small (200 tokens)	Better retrieval
Large (1000 tokens)	More context

A common heuristic:

$\text{Chunk Size} = 300 \text{ tokens}$

Where overlap helps maintain context across chunks.

$overlap = 50$

Example:

from langchain.text_splitter import RecursiveCharacterTextSplitter

splitter = RecursiveCharacterTextSplitter(
chunk_size=300,
chunk_overlap=50
)

chunks = splitter.split_documents(documents)

Step 3 — Embedding the Data ↗️

Embeddings convert text into a high-dimensional vector that captures semantic meaning.

• Also called vectorization or encoding.
• Similar meaning → similar vectors.

Example embedding:

"What is Kubernetes?"
→ [0.12, -0.44, 0.88, ...]

Example code:

from openai import OpenAI

client = OpenAI()

embedding = client.embeddings.create(
model="text-embedding-3-large",
input="What is Kubernetes?"
)

Step 4 — Store in a Vector Database 🔢

Embeddings must be stored in a vector index.

Popular Vector DB options:

Database	Use Case
Pinecone	Fully managed vector database.
Weaviate	Supports hybrid search
FAISS	Opensource Vector DB by Meta
Qdrant	Lightweight, embedded vector search engine for in-process retrieval

Example architecture:

flowchart TD
    C["Chunks 📑"] --> E["Embedding Model ↗"️]
    E --> V["Vector DB 🔢"]

Python:

vector_db.add(
ids=[chunk_id],
embeddings=[embedding],
metadata={"source": "docs"}
)

Step 5 — Query Time Retrieval 🔎

5.1 Top-K Documents

Top-K Documents refers to selecting the K most relevant documents from a larger collection based on a similarity or ranking score.

K Value	Effect
Small K	Faster, more precise
Large K	More context, but more noise

flowchart TD
    Q["User Query ❓"] --> E["Embedding ↗️"]
    E --> S["Vector Similarity Search 🔎"]
    S --> D["Top-K Documents 📁"]


Mathematically we search using cosine similarity:

Python:

    results = vector_db.search(
    query_embedding,
    k=5
)

Shortcomings

Normal Vector Search can have Keyword mismatch and may Retrieve wrong chunk

5.2. Hybrid Search

Hybrid Search solve it by adding Keyword search:

Vector Search + Keyword Search (BM25)

Vector search excels at: Semantic similarity

Example: "car" ≈ "automobile"

BM25 excels at: Exact keywords

Example: "workspace-id" --> "aws-managed-grafana-workspace-id"

flowchart TD
    Q["User Query ❓"] --> E["Embedding ↗️"]
    E --> S["Vector Similarity Search 🔎"]
    S --> D["Top-K Documents 📁"]


Advantages

• Better recall
• Handles exact identifiers
• Better for code and technical docs
• Industry standard

5.3 Hypothetical Document Embeddings (HyDE )

Question: How do circuit breakers prevent cascading failures?

Standard RAG

Embedding is generated from the question.

HyDE

Instead of embedding the user's question directly:

First generate:

Circuit breakers prevent cascading failures
by temporarily stopping requests to unhealthy
services and allowing recovery probes.

Then embed THAT answer.

Embedding a hypothetical answer creates a vector closer to the target documents.

Feature	Basic RAG	Hybrid Search	HyDE
Semantic retrieval	✅	✅	✅
Keyword matching	❌	✅	❌
Recall quality	Medium	High	High
Cost	Low	Medium	Higher
Latency	Low	Medium	Higher
Additional LLM call	❌	❌	✅
Works with technical identifiers	Weak	Excellent	Moderate
Production adoption	Very High	Extremely High	Growing

Step 6 — Prompt Construction 💬

Now we inject retrieved documents into the prompt.

Example prompt template:

You are a helpful assistant.

Use the context below to answer the question.

Context:
{retrieved_docs}

Question:
{user_query}

Example

prompt = f"""
Answer the question using the context below.

Context:
{docs}

Question:
{query}
"""

Step 7 — Generate Answer with LLM 📃

Now the LLM generates the answer grounded in retrieved knowledge.

flowchart TD
    P[Prompt + Retrieved Context ℹ️] --> LLM["LLM Generation 📃"]
    LLM --> A["Answer 💬"]

response = client.chat.completions.create(
    model="gpt-4.1",
    messages=[{"role": "user", "content": prompt}]

Production Architecture

A scalable RAG architecture looks like this:

flowchart TD

    A["User App"]--> B["API Server"]

    B --> C["Vector Database<br/>(Retrieval)"]

    B --> D["LLM API<br/>(Generation)"]

    C --> E["Response"]
    D --> E

Example Tech Stack

Layer	Tools
Ingestion	Airflow
Embeddings	OpenAI
Vector DB	Pinecone
Orchestration	LangChain
API	FastAPI
