📋 Evaluating a Hypothesis

A model that fits the training data very well is not necessarily a good hypothesis.

A model can have low training error but still perform poorly on new data due to overfitting:

• Low training error
• High error on unseen data

---

Choosing Between Multiple Models

Suppose we are trying polynomial regression with different degrees:

$$d = 1, 2, 3, \dots$$

Each degree defines a different hypothesis class.

We need a principled way to choose the best $d$ without biasing our evaluation.

A good model has:

• Low training error
• Also, Low test error

If training error is low but test error is high, the model is overfitting.

To properly select a model:

1. Train parameters on the training set
2. Choose model complexity using the cross-validation set
3. Report final performance using the test set

---

Splitting the Dataset

To properly evaluate performance, we split the dataset into:

A common split is:

• Training set: 60%
• Cross-validation set: 20%
• Test set: 20%

Train and Evaluate the Model

1. Split data into training and test sets.
2. Train the model by minimizing the regularized cost $J({\theta})$.
3. Obtain the optimal parameter vector ${\theta}$.
4. Compute the test error $J_{\text{test}}({\theta})$ on unseen data.
5. Compare training and test errors to diagnose:
   • High Bias (Underfitting)
   • High Variance (Overfitting)

---

Data Sets

1. 📚 Training set $J_{\text{train}}(\Theta)$

Typically, 60-70% of training data

• Training error tells us how well the model fits known data.

Using only the training set to learn parameters $\Theta$ by minimizing Minimize training error cost:

$$J_{\text{train}}(\Theta)$$ $$J({\theta}) = \frac{1}{2m_{\text{train}}} \sum_{i=1}^{m_{\text{train}}} \left( h_{{\theta}} \left( \mathbf{x}^{(i)} \right)- y^{(i)} \right)^2+ \frac{\lambda}{2m_{\text{train}}} \sum_{j=1}^{n} \theta_j^2$$

where:

• $m_{\text{train}}$ = number of training examples
• $n$ = number of features
• $\lambda$ = regularization parameter
• $h_{{\theta}}(\mathbf{x})$ = model prediction

2. 📘 Cross Validation Set $J_{\text{cv}}(\Theta)$

Used for Model Selection (Validation)

For each trained model $\Theta^{(d)}$, compute:

$$J_{\text{cv}}\big(\Theta^{(d)}\big)$$

using the cross-validation set.

Choose the polynomial degree:

$$d^* = \arg\min_d J_{\text{cv}}\big(\Theta^{(d)}\big)$$

This selects the model that generalizes best among the candidates.

$$J_{\text{test}}({\theta}) = \frac{1}{2m_{\text{test}}} \sum_{i=1}^{m_{\text{test}}} \left( h_{{\theta}} \left( \mathbf{x}^{(i)}_{\text{test}} \right)- y^{(i)}_{\text{test}} \right)^2$$

Important

The test error does not include the regularization term.

Regularization is used only during training to learn the parameters.

3. 📗 Test set $J_{\text{test}}(\Theta)$

Remaining 20-30% of training data

• Test error tells us how well the model generalizes.

After choosing $d^*$, estimate generalization error using:

$$J_{\text{test}}\big(\Theta^{(d^*)}\big)$$

The test set is used only once, at the very end.

• The test set must remain untouched until the very end.

---

Test Set Error Examples

1. Linear Regression

For linear regression, the test error is:

$$J_{\text{test}}(\Theta) = \frac{1}{2 m_{\text{test}}} \sum_{i=1}^{m_{\text{test}}} \left( h_\Theta\big(x_{\text{test}}^{(i)}\big)- y_{\text{test}}^{(i)} \right)^2$$

where:

• $m_{\text{test}}$ is the number of test examples
• $h_\Theta(x)$ is the hypothesis function

This measures the average squared error on unseen data.

2. Classification Logistic Regression

Given a training set, learn the parameter vector $\Theta$ by minimizing the logistic regression cost function:

$$J_{\text{train}}(\Theta) = -\frac{1}{m_{\text{train}}} \sum_{i=1}^{m_{\text{train}}} \left[ y^{(i)} \log h_\Theta(x^{(i)})+ (1 - y^{(i)}) \log \big(1 - h_\Theta(x^{(i)})\big) \right]$$

where

$$h_\Theta(x) = \sigma(\Theta^T x) = \frac{1}{1 + e^{-\Theta^T x}}$$

After learning $\Theta$ using the training set, evaluate performance on the test set.

The test set cost is:

$$J_{\text{test}}(\Theta) = -\frac{1}{m_{\text{test}}} \sum_{i=1}^{m_{\text{test}}} \left[ y_{\text{test}}^{(i)} \log h_\Theta(x_{\text{test}}^{(i)})+ (1 - y_{\text{test}}^{(i)}) \log \big(1 - h_\Theta(x_{\text{test}}^{(i)})\big) \right]$$

Important:

• $\Theta$ is not retrained on the test set.
• We simply plug the learned $\Theta$ into the test cost formula.

Misclassification error

For classification, we often use misclassification error (also called 0/1 error).

Define:

$$\text{err}(h_\Theta(x), y) = \begin{cases} 1 & \text{if } h_\Theta(x) \ge 0.5 \text{ and } y = 0 \\ 1 & \text{if } h_\Theta(x) < 0.5 \text{ and } y = 1 \\ 0 & \text{otherwise} \end{cases}$$

This gives:

• 1 for an incorrect prediction
• 0 for a correct prediction

Classification Average Test Error

The overall test error is:

$$\text{Test Error} = \frac{1}{m_{\text{test}}} \sum_{i=1}^{m_{\text{test}}} \text{err}\big( h_\Theta(x_{\text{test}}^{(i)}), y_{\text{test}}^{(i)} \big)$$

This gives the proportion of test examples that were misclassified.

---

Error Analysis

A practical and effective approach to solving machine learning problems is:

1. Start with a simple algorithm
2. Implement it quickly
3. Evaluate it early using cross-validation data

Avoid over-engineering before you understand where the model is failing.

Step 1 — Plot Learning Curves

Learning curves help answer questions like:

• Would more training data help?
• Is the model suffering from high bias?
• Is it suffering from high variance?
• Would more features improve performance?

They give direction before investing more time.

Step 2 — Manually Inspect Errors

After evaluating on the cross-validation set:

• Look at misclassified examples
• Try to identify patterns in the errors

Example

Suppose:

• 500 total emails
• 100 misclassified

Instead of guessing improvements, manually inspect those 100 emails.

You might categorize them:

• Phishing emails
• Promotional emails
• Personal emails
• Password theft attempts

If most errors are password-theft emails, that suggests the model is missing features specific to that category.

You could then:

• Add features related to suspicious links
• Add features related to urgent security language
• Detect specific keyword patterns

Step 3 — Try Improvements Systematically

Every time you introduce a change:

• Add a feature
• Apply stemming
• Modify preprocessing
• Adjust regularization

You must measure the impact using a single numerical metric.

Without a numerical value, you cannot objectively compare changes.

Example: Stemming

Stemming treats variations of a word as the same root: [ fail , failing, failed]

If error rate drops from:

$$5\% \rightarrow 3\%$$

That is a strong improvement. Keep it.

Example: Case Sensitivity

Suppose distinguishing between uppercase and lowercase changes error from:

$$3\% \rightarrow 3.2\%$$

That is worse. Do not keep the feature.

Core Principle

Always:

1. Make one change at a time
2. Measure cross-validation error
3. Keep only changes that reduce error

Avoid guessing. Let the data guide decisions.

Troubleshooting prediction errors by:

• Getting more training examples
• Trying smaller sets of features
• Adding new features
• Trying polynomial features
• Increasing or decreasing $\lambda$

we need a reliable way to evaluate the new hypothesis.

---

Key Insight

Error analysis turns machine learning from random tweaking into a systematic engineering process.

Instead of asking:

"What should I try next?"

You ask:

"Where is the model failing, and why?"

Then improve it in a targeted way.
